Premade Pouch Stand Up Doypack Granule Ceev Multihead Weigher Tsis Siv Neeg Kab rov tav Multifunctional Ntim Tshuab

Cov Khoom Piav Qhia HorizonTop-series Kab rov tav ntim tshuab - Kab rov tav ua ntej- ua lub hnab tsis siv neeg ntim tshuab series tsim los ntawm peb lub tuam txhab tau txais kev siv tshuab thoob ntiaj teb thiab muab los ntawm European classical packing tshuab. Nrog kev sib xyaw ntawm cov tshuab ntim khoom tam sim no, ...

Xa kev nug

Khoom Description

HorizonTop--Series multi-functional HFFS hnab ntim tshuab yog tsim los rau doypack nrog zipper, nrog kev ua haujlwm ntawm kev ua lub qhov dai lossis cov duab tshwj xeeb.

HorizonTop--Series ntim tshuab tuaj yeem ua tiav lub hnab ntim khoom, pub mis, ntsuas, txhaws, sealing, hnub luam ntawv, nitrogen filling, suav, thiab xa khoom tiav. Nws yog qhov tsim nyog rau kev sau cov khoom sib txawv xws li hmoov, granule, kua, qab zib thiab lwm yam tsis muaj dej ntws tawm thaum nruab nrog cov khoom noj thiab ntsuas.

Cov ntaub ntawv tshuab

Qauv	HorizonTop--210	HorizonTop--250	HorizonTop--360	HorizonTop--450	HorizonTop--500
Ceev	30-50 hnab / min	30-45 hnab / min	15-35 hnab / min	40-80 hnab / min	3-15 hnab / min
Qhov tseeb	± 1.5%	± 1.5%	± 1.5%	± 1.5%	± 1.5%
Hnab dav	55-200 hli	80-250 hli	120-350 hli	100 ~ 200 hli	120-400 hli
Hnab qhov siab	100-280 hli	100-280 hli	100-280 hli	100 ~ 280 hli	150-500 hli
muaj peev xwm	1-5 kg	1-5 kg	1-5 kg	1-5 kg	1-15 kg
Hwj chim	4 kwv	4 kwv	4 kwv	6 kws	4 kwv
Kev siv roj	0.6m3 / min	0.6m3 / min	0.6m3 / min	0.6m3 / min	0.6m3 / min
Cua siab tus nqi	0,6MPa	0,6MPa	0,6MPa	0,6MPa	0,6MPa
Qhov hnyav	1450kg ib	1700kg ib	2200 Kg	2000 kg	8 00kg
Loj (mm)	290010001390	350010001390	390010001390	380010001200	230010001390
Warranty	5 xyoo	5 xyoo	5 xyoo	5 xyoo	5 xyoo

product-1-1

1.Zipper Release 2.Film Unwind 3.Bottom Holes Punching 4.Bag Forming 5.Film Guide

6. Kab rov tav Zipper Foob 7.Kab hauv qab Foob 8.Vertical Zipper Foob 9.Vertical Seal I 10.Vertical Foob II

11.Tear Notch 12.Photocell 13.Servo Advance 14.Cutting 15.Pouch Catching

16.Pouch Opening 17.Air Flushing 18.Filling I 19.Filling II 20.Top Seal I 21.Top Seal II 22.Finished Product 23.Outlet

product-1-1

Lub tshuab filling tsuas yog rau koj siv. Peb yuav muab cov kev daws teeb meem zoo tshaj plaws rau koj raws li koj cov khoom txav, viscosity, ntom, ntim, qhov ntev thiab lwm yam.

A. Cov hmoov ntim tshuaj

Servo Screw Auger Filler yog tshwj xeeb rau cov hmoov filling xws li cov as-ham hmoov, seasoning hmoov thiab lwm yam.

B. Ua kua ntim tshuaj

Piston Pump Filler yog tshwj xeeb rau cov kua filling xws li dej, kua txiv, ntxhua khaub ncaws, ketchup thiab lwm yam.

C. Khoom ntim tshuaj

Combination multi-head weigther yog tshwj xeeb rau cov khoom ntim xws li khoom qab zib, txiv ntseej, pasta, thiab txiv hmab txiv ntoo qhuav thiab lwm yam.

D. Granule Packing Solution

Volumetric Cup Filler yog tshwj xeeb rau granule filling xws li ntsev, sugat, thiab seasonings thiab lwm yam.

E. Ntau Cov Txheej Txheem Ntim

Yog xav paub ntxiv, txais tos hu rau peb.

Tsom ntsoov rau Cov Lus Qhia

Independent Film Unwind Unit

1. Ua kom muaj kev tswj xyuas zoo ntawm zaj duab xis tensile quab yuam;

2. Yooj yim dua rau zaj duab xis yob dav lossis lub hnab ntim tshwj xeeb;

3. Zoo dua doypack txoj kev;

Servo Advance System

1. Digital specification switching, yooj yim thiab yooj yim;

2. Lub hnab ruaj khov ua ntej nrog kev sib txawv tsawg;
3. Loj torquemoment ntawm lub hnab ua ntej, haum rau loj ntim

Dual Filling Chaw nres tsheb

1. Txo lub sij hawm sau los ntawm ib nrab;

2. Txhim kho qhov raug;
3. tuaj yeem sau 2 khoom ib txhij.

Zipper Function

1.Independent zipper unwind ntaus ntawv;

2. ruaj khov zipper tensile quab yuam tswj;
3.Txawm tias zipper foob.
